Load cells PR 6246

Tension load load cell specially designed for weighing suspended hoppers and high-precision dosing systems

Request this product Download datasheet

load cell pr 6246

Ultra-precise

Load cell for dosing applications

Large load range

From 100 kg to 3 tonnes

Associated installation kit

PR 6046

Usable in Ex zone

1, 2, 20, 21, 22 and FM DIV 1

Product details Tension Load Cell S-Type PR 6246

The load cells in the PR 6246 series are specially designed for high-precision weighing of process vessels and for high-precision dosing. Due to the suspended mounting of the vessel, movements caused by mechanical or thermal contraction or expansion of the vessel or the support structure can be compensated. A special design feature is the compact design combined with a high overload range of up to 150% and the highest accuracy class up to C6. In addition to high measuring accuracy and reproducibility, this series is characterised above all by unrivalled reliability, robustness and stability, which enables years of trouble-free operation without any readjustment. The associated installation kit ensures that the force is always optimally applied to the sensor and minimises the influence on the measuring accuracy while maintaining very high reproducibility and perfect linearity. Special strain gauge technology enables a particularly wide operating temperature range. The hermetically sealed encapsulation in conjunction with the special TPE cable allows the sensor to be used even under extreme operating conditions. The entire measuring chain can be pre-adjusted without a reference weight. The "matched output" technology allows a damaged load cell to be replaced in a time-saving manner without the need for recalibration. As an option, load cells from this series are also available as an Ex version for use in intrinsically safe circuits.

Applications

  • Fill quantity control
  • Filling and Dosing
  • Weighing

Certifications

  • ATEX
  • FM
  • IEC-EX
  • NTEP
  • OIML

Specifications

Product type

Product handling

  • Suspended mounting of the hopper
  • Can be used under extreme operating conditions

IP protection class

  • IP68/IP69K



Material

  • Stainless steel 1.4542

Webinar Load cell as central heart of weighing

  • Introduction of load cells and weight transmitter portfiolio incl. application areas
  • Realized weighing applications
  • Benefits of Minebea Intec weighing solutions

Watch for free


Industrial solutions Our products for your production processes

Our systems and services are oriented towards the requirements of our customers from a wide range of industries. In this way, we ensure that with Minebea Intec you can design your production processes safely and efficiently without having to make compromises. This starts with individual product features and stops only after exceeding global standards.

  • Food & Beverage
  • Agriculture
  • Building Materials
  • Machinery / OEM
1 of 2
2 of 2

Food & Beverage

Minebea Intec is a leading supplier of weighing and inspection technologies to the food and beverage production industry. Armed with a deep understanding of the challenges food and drink manufacturers face, the company has developed a range of products and solutions that are perfectly tailored to meet their needs in relation to quality and food/drink safety, while also enhancing efficiency and protecting production equipment.

Our solutions for food and beverage industry

Agriculture

The processes in the agricultural industry require robust, reliable solutions with safe measurement results. From truck weighing to metal detection, Minebea Intec’s extensive range of weighing and foreign body inspection products, both automated and manual, has a high-quality solution for every need.

Our solutions for agriculture industry

Building Materials

For the weighing of building materials, the Minebea Intec portfolio offers the appropriate robustness, durability and IP protection class. Robust dosing, filling and metal detection equipment is also supplied.

Our solutions for the building materials industry

Machinery / OEM

Process integrators and machine manufacturers in various industry sectors can benefit from the precision, hygienic design, corrosion resistance and ingress protection offered by Minebea Intec equipment. A wide product range is available.

Our solutions for machinery / OEM

Mediacenter

Category File Name File Size File Type
Brochure
Brochure Brochure // Vessel and Silo Weighing 5,99 MB pdf
Manual
Manual Tension Load Cell S-Type PR 6246 3,02 MB pdf
Datasheet
Datasheet Datasheet // Tension S-type load cell PR 6246 1,46 MB pdf
